| Norm | AMATEUR RADIO (restriction : in emission use with amator radio certificate obligatory) |
| Mode | FM ( Wide/Narrow ) |
| Frequency range | RX/TX : 144-146 MHz / 430-440 MHz |
| Power | LOW : 5W / MIDDLE : 15W / HIGHT : 25W VHF -- 20W UHF(large cooling box) |
| Input voltage | 13,8V DC |
| Memories | 200 channels |
| Channel spacing | 12.5 / 20 / 25 KHz |
| Step of increment | 2.5 / 5 / 6.25 / 10 / 12.5 / 20 / 25 / 30 / 50 KHz |
| Working | UU / UV / VU / VV |
| RELAY MOD / OFFSET | Yes : allows to enter a relay with two different frequency |
| TONE BURST | Yes : 1000Hz / 1450Hz / 1750Hz / 2100Hz |
| CTCSS / DCS (encoder/decoder) | 52 CTCSS / 1024 DCS : sub-audio code to activate repeater like selective tone |
| DTMF (encoder) | Yes : tones selected to activate repeater, internet gateway and other items |
| DOUBLE WATCH function | Yes |
| VOX function | Yes : this feature triggers your microphone sound (hands free) |
| TOT function | Yes : time out timer |
| CTCSS / DCS SCAN function | Yes |
| SCAN function | Yes : automatic search of busy channels |
| REVERSE function | Yes : the current channel RX frequency will be switched to TX frequency |
| TALK AROUND function | Yes : switch RX/TX frequencies and CTCSS/DCS code to avoid using repetear |
| Various functions | Possibility to lock the start by code (default code 123456) |
| Bonus | Backlit keys + Jack plug for external loud speaker + 6 functions keys PF1 to PF6 with 3 functions each + menu order can be personalized |
| Mike | With speaker incorpored and programmable keys |
| Display | Large color multifunction TFT display adjustable to 180 ° |
| Level display | RX signal + TX power + channel number or frequency + various functions ... |
| Options | Programming cable + software |
| Programmable by software | Yes |
| Includ | Detachable power cable + fixing bracket + screws + microphone holder + manual in French&English |
| Size | 122 (l) x 165 (L) x 35 (H) mm |
| Weight | 480 gr |
